Intel I6737p 2.9GHz/270w 32c/144MB Ddr5 6400mt/s

Processor

Processor manufacturer

Intel

Processor model

6737P

Processor base frequency

2.9 GHz

Processor family

Intel Xeon 6

Processor cores

32

Processor socket

LGA 4710

Processor threads

64

Intel® UPI Speed

24 GT/s

Processor operating modes

64-bit

Processor boost frequency

4 GHz

All core Turbo frequency

4 GHz

High priority cores

12

High priority core frequency

3 GHz

Low priority cores

20

Low priority core frequency

2.8 GHz

Processor cache

144 MB

Processor cache type

L3

Thermal Design Power (TDP)

270 W

Number of QPI links

4

Processor codename

Granite Rapids

Memory

Maximum internal memory supported by processor

4 TB

Memory types supported by processor

DDR5-SDRAM

Memory clock speeds supported by processor

6400 MHz

Memory channels

Octa-channel

ECC

Yes

Graphics

On-board graphics card

No

Discrete graphics card

No

On-board graphics card model

Not available

Discrete graphics card model

Not available

Features

Execute Disable Bit

Yes

Maximum number of PCI Express lanes

88

PCI Express slots version

5.0

Supported instruction sets

AMX, AVX, AVX 2.0, AVX-512, SSE4.2

Scalability

2S

Embedded options available

Yes

Processor special features

Intel® Hyper Threading Technology (Intel® HT Technology)

Yes

Intel® Turbo Boost Technology

2.0

Intel® AES New Instructions (Intel® AES-NI)

Yes

Intel Trusted Execution Technology

Yes

Intel® Speed Shift Technology

Yes

Intel® Transactional Synchronization Extensions

Yes

Intel® Total Memory Encryption

Yes

Intel® Control-flow Enforcement Technology (CET)

Yes

Intel® Crypto Acceleration

Yes

Intel® Platform Firmware Resilience Support

Yes

Intel® Trust Domain Extensions (Intel® TDX)

Yes

Intel VT-x with Extended Page Tables (EPT)

Yes

Intel® Secure Key

Yes

Intel® OS Guard

Yes

Intel Software Guard Extensions (Intel SGX)

Yes

Intel 64

Yes

Intel Virtualization Technology (VT-x)

Yes

Intel Virtualization Technology for Directed I/O (VT-d)

Yes

Intel® Boot Guard

Yes

Intel® Deep Learning Boost (Intel® DL Boost) on CPU

Yes

Intel® Speed Select technology - Performance Profile (Intel® SST-PP)

No

Intel® Resource Director Technology (Intel® RDT)

Yes

Intel® Volume Management Device (VMD)

Yes

Intel® Run Sure Technology

Yes

Mode-based Execute Control (MBE)

Yes

Intel® Speed Select Technology - Base Frequency (Intel® SST-BF)

Yes

Intel® Total Memory Encryption - Multi Key

Yes

Intel® QuickAssist Software Acceleration

Yes

Intel® QuickAssist Technology (QAT)

4

Intel® Dynamic Load Balancer (DLB)

4

Intel® Data Streaming Accelerator (DSA)

4

Intel® In-memory Analytics Accelerator (IAA)

4

Intel® Advanced Matrix Extensions (AMX)

Yes

Intel® Speed Select Technology – Core Power

Yes

Intel® Speed Select Technology – Turbo Frequency

Yes

Operational conditions

Tcase

82 °C

DTS Max

102 °C

Technical details

Package carrier

E2B
