Core i3 Processor i5-13400t 1.30 GHz 20MB Smart Cache - Tray

Introduction

Intel® Gaussian & Neural Accelerator
Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.

Intel® Deep Learning Boost (Intel® DL Boost)
A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Intel® Speed Shift Technology
Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

Intel® Turbo Boost Technology
Intel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.

Processor

Processor manufacturer

Intel

Processor generation

13th gen Intel® Core™ i5

Processor model

i5-13400T

Processor family

Intel® Core™ i5

Processor cores

10

Processor socket

LGA 1700

Processor threads

16

Processor operating modes

64-bit

Performance cores

6

Efficient cores

4

Processor boost frequency

4.4 GHz

Performance-core boost frequency

4.4 GHz

Performance-core base frequency

1.3 GHz

Efficient-core boost frequency

3 GHz

Efficient-core base frequency

1 GHz

Processor cache

20 MB

Processor cache type

Smart Cache

Box

N

Processor base power

35 W

Maximum turbo power

82 W

Stepping

C0

Bus type

DMI4

Maximum number of DMI lanes

8

Memory bandwidth supported by processor (max)

76.8 GB/s

Processor codename

Raptor Lake

Processor ARK ID

230577

Memory

Maximum internal memory supported by processor

128 GB

Memory types supported by processor

DDR4-SDRAM, DDR5-SDRAM

Memory channels

Dual-channel

Memory bandwidth (max)

76.8 GB/s

Graphics

On-board graphics card

Y

Discrete graphics card

N

On-board graphics card model

Intel UHD Graphics 730

On-board graphics card outputs supported

Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1

On-board graphics card base frequency

300 MHz

On-board graphics card dynamic frequency (max)

1550 MHz

Number of displays supported (on-board graphics)

4

On-board graphics card DirectX version

12.0

On-board graphics card OpenGL version

4.5

On-board graphics card maximum resolution (DisplayPort)

7680 x 4320 pixels

On-board graphics card maximum resolution (eDP - Integrated Flat Panel)

5120 x 3200 pixels

On-board graphics card maximum resolution (HDMI)

4096 x 2160 pixels

On-board graphics card refresh rate at maximum resolution (DisplayPort)

60 Hz

On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)

120 Hz

On-board graphics card refresh rate at maximum resolution (HDMI)

60 Hz

On-board graphics card ID

0x4682

Discrete graphics card model

Not available

Number of execution units

24

Multi-Format Codec Engines

1

Features

Thermal solution specification

PCG 2020D

Execute Disable Bit

Y

Idle States

Y

Thermal Monitoring Technologies

Y

Market segment

Desktop

Use conditions

PC/Client/Tablet

Maximum number of PCI Express lanes

20

PCI Express slots version

5.0, 4.0

PCI Express configurations

1x16+1x4, 2x8+1x4

Supported instruction sets

SSE4.1, SSE4.2, AVX 2.0

Scalability

1S

CPU configuration (max)

1

Embedded options available

N

Direct Media Interface (DMI) Revision

4.0

Export Control Classification Number (ECCN)

5A992C

Commodity Classification Automated Tracking System (CCATS)

740.17B1

Processor special features

Intel Enhanced Halt State

Yes

Intel® Hyper Threading Technology (Intel® HT Technology)

Y

Intel® Turbo Boost Technology

2.0

Intel® Quick Sync Video Technology

Y

Intel® Clear Video HD Technology (Intel® CVT HD)

Y

Intel® AES New Instructions (Intel® AES-NI)

Y

Enhanced Intel SpeedStep Technology

Y

Intel® Speed Shift Technology

Y

Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0

Y

Intel® Control-flow Enforcement Technology (CET)

Y

Intel® Thread Director

Y

Intel VT-x with Extended Page Tables (EPT)

Y

Intel® Secure Key

Y

Intel® OS Guard

Y

Intel 64

Y

Intel Virtualization Technology (VT-x)

Y

Intel Virtualization Technology for Directed I/O (VT-d)

Y

Intel Turbo Boost Max Technology 3.0

N

Intel® Boot Guard

Y

Intel® Deep Learning Boost (Intel® DL Boost)

Y

Intel® Volume Management Device (VMD)

Y

Mode-based Execute Control (MBE)

Y

Intel® Standard Manageability (ISM)

Y

Intel® Virtualization Technology with Redirect Protection (VT-rp)

Y

Technical details

OpenGL support

Yes

Target market

Gaming

OpenCL version

3.0

Launch date

Q1'23

Status

Launched

Operational conditions

Tjunction

100 °C

Logistics data

Harmonized System (HS) code

8542310001

Weight & dimensions

Processor package size

45 x 37.5 mm

Other features

L2 cache

9728 KB

Maximum internal memory

128 GB

Graphics output

eDP 1.4b, DP 1.4a, HDMI 2.1

Packaging data

Package type

Tray
