Product Details
Introduction
Converts a DisplayPort signal into HDMI_x000D_
Supports resolutions up to 1920x1080@60Hz_x000D_
Can be used to add a secondary monitor for extended or mirrored desktop_x000D_
Compact dimensions for easy installation and use_x000D_
2 year warranty_x000D_
_x000D_
The Lindy DisplayPort to HDMI Converter is ideal for connecting a DisplayPort equipped source such as a PC or laptop to an HDMI monitor or HDTV. It supports high definition video resolutions up to 1920x1080@60Hz and allows Audio pass-through if supported by the video source._x000D_
_x000D_
This converter can also be used to add a secondary monitor for extended or mirrored desktop modes to increase productivity and screen real estate. Internal copper shielding provides enhanced reliability and compatibility. The converter is also ideally suited for travelling due to its compact, lightweight form factor and convenient plug & play installation._x000D_
Features
Connector 1 form factor
Straight
Connector 2 form factor
Straight
Cable length
0.15 m
Connector 1
DisplayPort
Connector 2
HDMI
Connector 1 gender
Male
Connector 2 gender
Female
HDMI version
1.3a
HDCP
Y
HDCP version
1.4
DisplayPort version
1.1
Maximum resolution
1920 x 1080 pixels
Supported graphics resolutions
1920 x 1080 (HD 1080)
Data transfer rate
4.45 Gbit/s
Bend radius (min)
6.5 cm
Product colour
Black
Chipset
NXP PTN3361
Jacket material
Polyvinyl chloride (PVC)
Connector housing material
Thermoplastic elastomer (TPE)
Certification
CE, UKCA, FCC, RoHS, REACH
Operational conditions
Operating temperature (T-T)
-20 - 80 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
20 - 90%
Weight & dimensions
Cable diameter
6.5 mm
Connector 1 dimensions (WxDxH)
21.9 x 40 x 11.4 mm
Connector 2 dimensions (WxDxH)
20 x 36 x 11 mm
Weight
36 g
Packaging data
Quantity per pack
1 pc(s)
Package width
160 mm
Package depth
20 mm
Package height
160 mm
Package type
Polybag
Package weight
44 g
Manual
Y
