Hdmi Cable - 4k 60hz - 10m - Gold (36507)

Introduction

The halogen-free sheath material of the LSZH cable makes the product suitable for use in public spaces with its low smoke emission and elimination of toxic halogen emissions. Ideal for safety-critical installations, this cable is perfectly suited for public environments such as schools, transport hubs, and government buildings, anywhere safety compliance and performance are essential.

The cable features a double shielded construction with 30AWG bare copper for premium performance featuring gold connectors and gold flashed contacts to maintain signal integrity and reliability.

Supporting 18Gbps bandwidth the Lindy LSZH HDMI® Cable can support UHD resolutions up to 3840x2160@60Hz 4:4:4 8bit. Whilst also transmitting up to 32 Channel audio including Dolby® True HD & DTS-HD Master Audio.

The Lindy LSZH HDMI® Cable is available in lengths from 0.5m to 10m.

The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

Features

Cable length

10 m

Connector 1

HDMI Type A (Standard)

Connector 2

HDMI Type A (Standard)

Connector 1 gender

Male

Connector 2 gender

Male

Connector 1 form factor

Straight

Connector 2 form factor

Straight

HDMI cable type

High Speed HDMI cable

Product colour

Black

3D

Yes

Supported graphics resolutions

3840 x 2160

Supported video modes

2160p

Dolby technologies

DTS-HD Master Audio, Dolby TrueHD

Data transfer rate

18 Gbit/s

Supported digital audio channels (uncompressed)

32

Maximum refresh rate

60 Hz

AWG wire size

28

Connector contacts plating

Gold

Cable material

Copper

Cable type

Round cable

Cable jacket material

Low smoke zero halogen (LSZH), Polyvinyl chloride (PVC)

Magnetically shielded

Yes

Shield material

Aluminium

Bending radius (min)

6 cm

Plug and Play

Yes

Colour sampling

4:4:4

Nominal attenuation

300kHz~825MHz<5dB 825MHz~2.475GHz<5dB 2.475GHz~4.125GHz<12dB 4.125GHz~5.1GHz<20dB

Operational conditions

Operating temperature (T-T)

-10 - 80 °C

Storage temperature (T-T)

-20 - 85 °C

Sustainability

Doesn't contain

Halogen

Certificates

Compliance certificates

REACH, RoHS

Weight & dimensions

Cable diameter

5.5 mm

Packaging data

Package type

Polybag

Quantity per pack

1 pc(s)
